Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen

Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen

    • Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen
    • Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen
    • Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen
  • Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen

    Product Details:

    Place of Origin: China,Shenzhen
    Brand Name: X-media
    Certification: CE/RoHS/ISO/CB/SASO/TUV/FCC/UL
    Model Number: P6mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 5sq.m
    Price: Negotiation
    Packaging Details: Flight case, wooden case and carton box and foam package
    Delivery Time: 8~10 working days
    Payment Terms: T/T, Western Union, MoneyGram,Cash
    Supply Ability: 5,000sq.m/month
    Contact Now
    Detailed Product Description
    Product Name: Advertisement Led Display Cabinet Material: Iron
    Module Size: 192x192mm Screen Dimension: Negotiation
    Brightness: 5500cd Warranty: 5 Years
    Life Time: 100,000H MTBF: 10,000H
    High Light:

    Waterproof Advertisement LED Display

    ,

    P6mm Outdoor Led Video Screen

    ,

    P6mm Advertisement LED Display

    HD IP65 Waterproof Advertisement LED Display, P6mm outdoor LED Video Screen



    Shenzhen X-Media Electronics Co.,Ltd is established in 2005. we are a leading manufacturer and provider of technical solution. We own our outstanding research and develop department and after-sales service workers, the separately design ability.Our product mainly included the RGB led display,outdoor full color led display,indoor full color led display, advertising led display,stage led display,led billboard,rental led display,stadium led display,led display module,car led sign display,hanging led display,mobile truck led display





    About our led displays



    1. Wide application field & short ROI time:

    commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen

    air port LED display screen, telecommunication LED display screen system for information showing and instruction .



    2. High Contrast ratio: 4000:1
    Which is a very high level to ensure a vivid image of our LED display screen system.



    3. First-class LED chip:
    Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system



    4. Clear vivid image quality:
    Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.



    Applications:

    Entertainment venues, broadcast, auditoriums, stage events, malls, market squares, offices, hotels, restaurants, banquets , sports, entertainment and other special event.

    Outdoor stage shows ,big concert, wedding background, media Facade, Video Productions

    perfect display solution for outdoor events such as exhibitions, conferences, awards shows, experimental marketing and corporate events





    Technology parameter

    1, Item Name p6 outdoor waterproof advertising led display with high definition image
    2, pixel tube:

    pixel pitch:6mm; primary colors: pure red+ pure green +pure blue;

    color composing:3 in 1 or 1R1G1B

    Density 62500dots/sq m; SMD3528

    3 , unit box

    module size:192mm×196mm; Module resolution:32*32

    cabinet thickness:(cold-roll steel sheet)150mm+(maintain)600mm;

    4, whole screen:

    the optimum viewing angel :horizontal 110°, vertical 50°

    viewing distance:10-300m;working temperature:-20°C~+45°C(-30°C ~+50°C optional) relative humidity:≤95%RH; Drive IC MBI5024



    5, operating voltage

    AC220V±10% or 110V±10% ,average consumption:500 W/sq m

    max consumption:≤650 W/ sq m.

    6, main parameter

    1) driving mode: 1/8 scan

    2) refreshing rate:≥400Hz/s

    3) frame frequency:≥60Hz/s

    4) gray scale/color:≥16.7Mcolors(Synchronized)

    5) manage gray:≥72bit

    6) brightness:≥7000cd/sq m

    7) color temperature condition:3500K~9500K,be adjustable

    8) adjusting style of brightness: hand movement/auto

    9) video signal: RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc. managing ability of signal:≥12bit.against Y revised curve: owns 3pcs above Y curve that can adjustable.

    10) average trouble-free time:≥5000hours

    11) evenness: between random adjacent pixel ≤0.5mm,module splicing space<1mm

    12) switch power loading:5V/40A

    13) display mode of computer:1024×768





    Top Sales P10 Outdoor HD Video Huge Advertising LED Video Wall High Quality 1/4 Scan Mode 0



    Advertising LED video wall case

    Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen 1

    Waterproof Advertisement LED Display , P6mm Outdoor Led Video Screen 2



    Shipping ang package:

    In our company all goods we can use our own freight forwarding, the cost can be low; But is you want use your own,

    it's ok. So normally we use air and sea, the packages are wooden and flight cases.



    Top Sales P10 Outdoor HD Video Huge Advertising LED Video Wall High Quality 1/4 Scan Mode 2

    The answers which you may care:

    1. We accept T/T and Western Union payment;

    2. The delivery time is about 12-15 working days after receiving your down payment;

    3. Two years warranty for free;

    4. We will send you an instruction manual before using,if still confused can contact us;









    FAQ

    1. Diversified products :
    Varieties of models for outdoor/indoor LED display screens,and customized cabinets available,meet all requirements and win more profits for customers.
    2. Experienced&Professional:
    10 years manufacturing experience on LED displays, professional workmanship & design.
    3. Best raw materials:
    Taiwan Epistar LED chip,high quality,high brightness and long life span.
    4. Competitive price:
    100% factory price,competitive and reasonable price.
    5. Strict quality control:
    100% testing before shipment , make sure our quality before delivery.
    6. Quality gurantee:
    All our LED display screens is more than 100,000 hours life span.
    7. Long warranty:
    Two year warranty, any quality problem during warranty time will be handled .

    8. Prompt &Professional service :
    Any inquires will be replied within 24 hours in working days and you’ll get helpful suggestions from us.



    Buy guides:
    In order to save you time avoid no necessary troubles ,please follow the steps bellowing :
    1,Dimension (Width and Height)
    2,Location of installation. (picture is best)
    3,Purpose. ( what are you going to do with the LED Curtain)
    4,Star effect or video effect which you need.



    How Contact us:
    Project represent : Jason Hu
    Whatsapp : +86 13538053596
    Wechat : +86-13538053596
    Email adress: Jason.hu@sovalueled.com
    www.advertisementleddisplay.com



    Welcome to visit our website and inquire us more info,waiting for you all the time!!!
