Product Details:
|
| Product Name: | LED Dance Floor Tile | Cabinet Material: | Steel Or Aluminum |
|---|---|---|---|
| Module Size: | 250x250mm | Screen Size: | Customized Design |
| Brightness: | 2100cd | Warranty: | 5 Years |
| Life Span: | 100,000H | MTBF: | 10,000H |
| High Light: | P3.91 LED Dance Floor Tiles,Indoor LED Dance Floor Tiles |
||
Indoor P3.91 Led Dance Floor Tile For Concert With 3840HZ Cabinet Size 1000x500mm
P3.91 led dance floor screen is designed into tiling module which turns the inanimate floor into an amazing stage video displaying surface with colors, patterns, videos and interactive performances. Designed based on concept of PASSION digital stage, which is a brand-new form digitally expressing floor. It also brings the best expressing form for floor for creating scene and interacting with shows in stage.
Adopt the color and brightness revised technology, the uniformity can reach the best level. The definition of showing picture is very high, Strong and durable aluminum alloy is used to build its structure and its facade is made of super-wearable rosin plastic, which endures hundreds of kgs stuff onto its facade moving and trampling.high grey grade, the screen picture will be extremely soft and vivid.
Think about dancing in fire, chasing tide, fabulous video…you can easily realize such things in dancing floor of disco hall, night club, T-stage, concerts, show dramas…
Dance Floor LED Screen feature
High Weight Load [ 200kg/S (S≥160x160 mm) Al-alloy Structure, Super-wearable Surface, Sealed Structure, High Protection Level (IP65) 14Bits Processing Depth, 3-in-1 SMD Technology, best color uniformity.
| High weight load 3 in 1 SMD outdoor p3.91 led dance floor screen for concert | |||||||||
| LED Lamps | Type | SMD1921(High Brightness LEDs) | |||||||
| LED Standard | Real Pixel(1R1G1B) | ||||||||
| Red Wavelength | 625-630nm | ||||||||
| Green Wavelength | 515-530nm | ||||||||
| Blue Wavelength | 465-475nm | ||||||||
| LED Module | Pixel Pitch | 3.91mm | |||||||
| Module Size | 250mx250m | ||||||||
| Module Resolution | 64dots*64dots | ||||||||
| LED Cabinet | Cabinet Size | 1000mmX500mm | |||||||
| Cabinet Resolution | 256pixels *128pixels | ||||||||
| Cabinets Material | steel or aluminium | ||||||||
| LED Display | Pixel Density | 65536pixels/sq.m | |||||||
| Drive IC | MBI5124 | ||||||||
| Power Supply | Series connection | ||||||||
| Brightness | >2100cd/sqm | ||||||||
| Display Color | 16.7million | ||||||||
| Viewing Angle | 110°(Horizontal),50°(Vertical) | ||||||||
| Best Viewing Distance | 1m~100m | ||||||||
| Max Power Consumption | 1000w/sq.m | ||||||||
| Average Power Consumption | 600 w/sq.m | ||||||||
| Refresh Rate | 3840hz | ||||||||
| Input Voltage | AC220V/50H or AC110V/60H | ||||||||
| Output Voltage | DC5V,40A | ||||||||
| Grey Scale Levels | 1024 | ||||||||
| Display Colors | R(1024) x G(1024) x B(1024) | ||||||||
| MTBF | 10,000 hours | ||||||||
| Life-span | 100,000 hours | ||||||||
| Protection Level | IP54 | ||||||||
| Failure percentage of leds | less than 0.0003 | ||||||||
| Working Temperature | -25℃~65℃ | ||||||||
| Drive Mode | 1/5 scan constant current | ||||||||
| Working Humidity | 10%~99% | ||||||||
| Control method | Synchronization & Asynchronization | ||||||||
| Control System | Control System | Mooncell | |||||||
| Software | LED Studio | ||||||||
| Input Signal | MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc | ||||||||
| PC Operating system |
Microsoft Windows 7, 98, 2000, XP and Vista |
||||||||
Advantages
Payment and delivery
FAQ
Q1: What's the pixel pitch for dance floor LED Display Screen ?
A1: Indoor&Outdoor P3.9mm/P6.25mm P10mm
Q2: Where is it used for?
A2: Indoor & Outdoor rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar And Linsn controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
Our Service and Mission
X-media has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on
Buy guides:
In order to save you time avoid no necessary troubles, please follow the steps bellowing :
1, Dimension ( Width and Height)
2, Location of installation. ( picture is best)
3, Purpose. ( what are you going to do with the LED Curtain)
4, Star effect or video effect which you need.
