ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV

ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV

    • ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV
    • ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV
    • ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV
    • ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV
  • ISO Fine Pixel Pitch LED Display 16 9 Golden Ratio For CCTV

    Product Details:

    Place of Origin: China,Shenzhen
    Brand Name: X-media
    Certification: CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
    Model Number: P1.25

    Payment & Shipping Terms:

    Minimum Order Quantity: 5sq.m
    Price: Negotiation
    Packaging Details: Flight case, wooden case and carton box and foam package
    Delivery Time: 8~10 working days
    Payment Terms: T/T, Western Union, MoneyGram,Cash
    Supply Ability: 5,000sq.m/month
    Contact Now
    Detailed Product Description
    Product Name: Fine Pitch LED TV Display Cabinet Material: Die-casting Aluminum
    Module Size: 200mmX168.75mm Screen Dimension: Customized Design
    Warranty: 5 Years Brightness: >1000CD
    Life Span: 100000H MTBF: 10000H
    High Light:

    ISO Fine Pixel Pitch LED Display

    ,

    16 9 Fine Pixel Pitch LED Display

    4K 8K  LED Display P1.25 module size 200*168.75mm for CCTV and indication





    Advantage



    1.16:9 golden ratio 600x337.5Die-casting Aluminum LED Panels, 80mm thickness, 7.6kg/pcs panel.



    2. high gray scale, 5000:1 contrast ratio,16 bit gray level, 3840Hz refresh rate

    3. seamless tiled display, <0.01mm.

    4. wide color gamut, good color uniformity, less glare and less shadow

    5. Natural heat dissipation, ultra silence

    6. die-casting aluminum, CNC fine finishing,good flatness

    7. with anti-slip handles, and high quality fast locks

    8. wireless connection,double backup design, with double control cards.

    9. support both rear and front service


    Specification



    Item Technical Specifications
    Pixel Pitch 1.25mm 1.56mm 1.875mm 2mm
    LED Configuration SMD1010 (3-IN-1) SMD1010 (3-IN-1) SMD1010 (3-IN-1) SMD1010 ( 3-IN-1)
    Pixel Density 640000pixels/sqm 409600pixels/sqm 284444pixels/sqm 160000pixels/sqm
    Module Size 200mm*168.75mm 200mm*168.75mm 300mm*168.75mm 200mm*337.5mm
    Cabinet Szie 600mm*337.5mm
    Cabinet Resolution 480*270pixels 384*216pixels 320*180pixels 240*135pixels
    Cabinet Material Die-casting Aluminum
    Cabinet Weight 7Kg
    Brightness 1000cd/sqm 1000cd/sqm 1000cd/sqm 1000cd/sqm
    Color Temperature 3500K-9500K 3500K-9500K 3500K-9500K 3500K-9500K
    Viewing Angle H:160°/V:160°
    Ave Power Consumption 230W/sqm 230W/sqm 230W/sqm 230W/sqm
    Max Power Consumption 800W/sqm 800W/sqm 800W/sqm 800W/sqm
    Drive Mode 1/27scan 1/32scan 1/32scan 1/32scan
    Best Viewing Distance ≥1.25m ≥1.56m ≥1.875m ≥2m
    Input Voltage AC220V/50HZ or AC110V/60HZ(±10%)
    Output Voltage 5V 40A
    Refresh Rate ≥3840Hz
    Frame Rate 50/60Hz/sec
    Protection Level IP43
    Life Span 100,000hours
    Malfunction dot rate <0.0001
    Storage Temp/Humidty —40~+60°C/10-80%RH
    Operating Temp/Humidty —25~+50°C/10-90%RH
    Input Signal RF,TV.RGB,S-VIDEO,PAL,DVI,HDMI,VGA,SDI,AVI,RGBHV,CVBS,etc
    Pc Operating System Microsoft Windows 7.8.10.98.2000.XP and Vista





    Product Details

    Wireless Connection Indoor Full Color LED Display 4K 8K 640000 Dots / Sqm Pixel Density



    Ultra HD Visual Feast

    Wireless Connection Indoor Full Color LED Display 4K 8K 640000 Dots / Sqm Pixel Density



    4K is not the end!

    Ultra-high resolution brings delicate display effect and and it is a perfect embodiment of new generation of UHD LED Display technology.

    Small pixel pitch easy reach FHD(1080P) even 4K(2160P) or more.

    Wireless Connection Indoor Full Color LED Display 4K 8K 640000 Dots / Sqm Pixel Density



    High contrast, High refresh rate

    Top quality black body SMD lamps and top level driver IC to provide the high refresh rate (≥2000Hz), high contrast ratio (3000:1), high grayscale (16bit), Display the smooth, colorful, clear, perfect image.

    Wireless Connection Indoor Full Color LED Display 4K 8K 640000 Dots / Sqm Pixel Density



    Wide viewing angel

    High quality SMD1010 black body lamps provide 160°/160° (horizontal / vertical) viewing angel make sure you can watch it in any directions.

    Wireless Connection Indoor Full Color LED Display 4K 8K 640000 Dots / Sqm Pixel Density



    Extreme flatness

    Cabinet is made by high precision die-cast aluminum alloy also first-class CNC machines to guarantee the screen is seamless and flatness like a mirror.

    Wireless Connection Indoor Full Color LED Display 4K 8K 640000 Dots / Sqm Pixel Density



    Trade Terms
    Payment terms:

    35% deposit before production, 65% balance before shipping

    -T/T:

    -Paypal

    -Western Union

    -Escrow

    Packing:

    -Standard Export Carton with fully Polyfoam or Pearl Wool

    -Flight case;

    -Anti-shaking wooden case

    Shipping:

    LED module: 3 to 5 working days upon receiving deposit payment

    LED display: 5 to 8 working days upon receiving deposit payment

    After-Sales-Service:

    -Lifetime with professional engineer support for free.
    -Within 1 year, supply spare parts for free if the machine

    has quality problem





    ur Service



    1. Warranty
    1) We provide warranty of all components for 5 full years. During this time, we will replace or repair our goods for free if there is something wrong with them.
    2) We will provide maintenance for a lifetime and charge for the raw materials only.

    2. Technology Training
    1) We provide the technology training for free, which contains the operation training and maintenance
    2) training in the factory.
    3) We will send our engineers to your country by negotiation.

    3. Maintenance and Consultation
    1) We provide full maintenance for a lifetime and charge for the raw materials only.
    2) We also provide lifetime consultation by E-mail, Skype, WhatsApp or other ways for free.

    4. Documents and Certification
    1) We provide the operation manual, software, test report and so on.
    2) We can also provide all kinds of certification such as CE, LVD, RoHS and so on.

    5. CAD Drawing and Fixing
    1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
    2) We will send our engineers to your place if we are expected after our negotiation.

    6. Additional Service
    1) We provide you the forwarding information, and some other information such as flight box, structure
