P4mm Huge Led Display , Commercial LED Screens 256mmx128mm

P4mm Huge Led Display , Commercial LED Screens 256mmx128mm
P4mm Huge Led Display , Commercial LED Screens 256mmx128mm P4mm Huge Led Display , Commercial LED Screens 256mmx128mm P4mm Huge Led Display , Commercial LED Screens 256mmx128mm

Large Image :  P4mm Huge Led Display , Commercial LED Screens 256mmx128mm

Product Details:
Place of Origin: Shenzhen,China
Brand Name: X-media
Certification: CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
Model Number: P4
Payment & Shipping Terms:
Minimum Order Quantity: 5sq.m
Price: Negotiation
Packaging Details: Flight case, wooden case and carton box and foam package
Delivery Time: 8~10 working days
Payment Terms: T/T, MoneyGram,Cash
Supply Ability: 5,000sq.m/month

P4mm Huge Led Display , Commercial LED Screens 256mmx128mm

Description
Product Name: Outdoor Full Color LED Display Big TV Advertising Screen Cabinet Material: Iron
Module Size: 256mmx128mm Screen Dimension: Customized Design
Brightness: >5500cd Warranty: 5 Years
Life Span: 100,000H MTBF: 10000H
High Light:

P4mm Huge Led Display

,

256mmx128mm Commercial LED Screens

,

P4mm Commercial LED Screens

5 Years Warranty Huge LED Screens P4 LED Digital Stadium Screen For Advertising





Specifications :



outdoor SMD P4
Resolution/mm 4mm
Pixel configuration 1R1G1B
Pixel density/pixels/m² 62500/m²
Module resolution 64x32
Module size/mm 256mmx128mm
View distance 4-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >5500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 SCANNING
Frame rate 60Hz
Refresh frequency >1200Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Service

1) Service principles
Response in time, solve problems as soon as possible and ensure the use.

2) Service period
In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.

3) Service scope
If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.



P4mm Huge Led Display , Commercial LED Screens 256mmx128mm 0



P4mm Huge Led Display , Commercial LED Screens 256mmx128mm 1





FAQ:

Q1: What's the warranty of your LED Display Screen ?

A1: We have a 5-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your pre-sale service and post-sale service?

A2: For pre-sale service: We have a professional sales team and 12 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the broken modules with spare parts.
Also, we can send technicians to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3: Whats your payment term? How long it takes to delivery?

A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.
Our average Production time is 8-10 days, after receiving the deposit.

Q4: What's the control system?

A4: For synchronization control: We use Nova, Linsn Or Colorlight control system.
For asynchronous control: We use ONBON or XIXUN control system.

Q5: How can you ensure the led display product quality?

A5: Our led display screen quality is our core competence, for 12 years, what we rely on.
We have each standard process to make quality products.
If any quality failures within warranty time, we will refund you .



Welcome to visit our website and inquire us more info,waiting for you all the time!!!
