P15.6mm LED Screen Curtain , LED Curtain Outdoor 4096 dots/m2

Large Image : P15.6mm LED Screen Curtain , LED Curtain Outdoor 4096 dots/m2

Product Details:

Place of Origin:	China,Shenzhen
Brand Name:	X-media
Certification:	CE/RoHS/ISO/CB/SASO/TUV/FCC/UL
Model Number:	P15.6

Payment & Shipping Terms:

Minimum Order Quantity:	5sq.m
Price:	Negotiation
Packaging Details:	Flight case, wooden case and carton box and foam package
Delivery Time:	8~10 working days
Payment Terms:	T/T, MoneyGram,Cash
Supply Ability:	5,000sq.m/month

Contact Now

P15.6mm LED Screen Curtain , LED Curtain Outdoor 4096 dots/m2

Description

Product Name:	Curtain Led Display	Cabinet Material:	Aluminum
Module Size:	1000X500mm	Screen Size:	Customized Design
Brightness:	7000cd/sqm	Warranty:	5 Years
Life Time:	100,000H	MTBF:	10,000H
High Light:	P15.6mm LED Screen Curtain , 4096 Dots/M2 LED Curtain Outdoor , 4096 Dots/M2 LED Screen Curtain

The Surface Of Building High Brightness P15.6 Curtain LED Display BMI Drive IC

Never black Screen

2pcs power supply

2pcs receing cards

2pcs sending cards

2pcs RJ45 network cables

Control system has dual backup

If one set of control system has problems. The whole led screen can not be affected.

Because other one set of control system will replace it to continue work.

Specification

1000x500mm die casting panel waterproof SMD 3806 p10.42 outdoor full color transparent curtain led displays

Technical Parameters:

Specifications	P5.95(semi outdoor)	P6.94(semi outdoor)	P6.25(outdoor)	P8.93(outdoor)	P10.42(outdoor)	P15.625(outdoor)
Pixel Size	5.95mm	6.94	6.25mm	8.93mm	10.42mm	15.625mm
Cabinet Size	500×1000	500×1000	500×1000	500×1000	500×1000	500×1000
Cabinet Resolution	84×168	72×144	80×160	56×112	48×96	32×64
LED Type	SMD3528	SMD3528	SMD3535	SMD3535	SMD3535	SMD3535
Pixel Composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Density	28224dots/ m 2	20736dots/ m 2	25600dots/ m 2	12544dots/ m 2	9216dots/ m 2	4096dots/ m 2
Drive Mode(Scan)	1/7 scan	1/6 scan	1/5 scan	1/4 scan	1/4 scan	Static
Gray scale	≥14bit	≥14bit	≥14bit	≥14bit	≥14bit	≥14bit
Brightness	≥2500cd/ m 2	≥2000cd/ m 2	≥6000cd/ m 2	≥6000cd/ m 2	≥6000cd/ m 2	≥6000cd/ m 2
Refresh Rate	≥ 1000HZ	≥ 1000HZ	≥ 1000HZ	≥1000HZ	≥ 1000HZ	≥ 1000HZ
AC Input	AC 220V/110V	AC 220V/110V	AC 220V/110V	AC 220V/110V	AC 220V/110V	AC 220V/110V
Maximum Power	400W/PCS	350W/PCS	500W/ PCS	300W/ PCS	250W/ PCS	400W/ PCS
Average Power	160W/PCS	140W/PCS	200W/ PCS	120W/PCS	100W/ PCS	160W/ PCS
Working Temperature	-20~ +50	-20 ~ +50	-20 ~ +50	-20 ~ +50	-20 ~ +50	-20 ~ +50

X-Media series Media Facade New dual backp design led screen

P15.6mm LED Screen Curtain , LED Curtain Outdoor 4096 dots/m2 3

Outdoor Mesh Led Display:

High protection of cabinet design with flexible shape.

Super light, super thin, super high transparency, high intensity item and easy maintenance

Light weight, extremely thin and high transparent cabinet:

Whole aluminum frame design, 70mm thickness, 16kg/sqm strip design, light and wind transparency, 60% extremely high wind pressure resistance

Higher 7000cd/sqm brightness

Fast installatin and easy front service

Ingress Protection IP65 Dustproof and Stormproof

High protections of high temperature, low temperature, lightning and corresion

Product package:

1pcs 1000x1000mm cabinet in one carton.

10pcs cartons in one wooden case.

10pcs frames in one wooden case.

Wooden case material is not wood, it does not need to be fumigated.

So it is very suitable used in import and export.

FAQ:

Q1: What does the dual backup means?
A1: The dual backup means if one set of control system can not work. Then other set of control can replace it to continue work. It will not affect whole led screen working situation.

Q2: Can its brightness can be higher?
A2: Yes. Of course, here is a solution to make the whole brightness to be 10000nits.

Q3: How long for the warranty? Can the warranty be longer?
A3: On usual, warranty is 5 years. Of course,according to customers' requirements,the warranty can be longer such as 5 years.

Q4: Except the whole screen and its accessories, what I need to prepare by myself?
A4: Power box, computer, external power cable, external network cable.

Q5: Can this transparent led screen has energy saving advantage?
A5: Yes. Of course, the energy saving is one of its important advantage. It can save a lots of power. In some degree, it can also save a lots of costs in electricity
