P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels

P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels
P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels

Large Image :  P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels

Product Details:
Place of Origin: China,Shenzhen
Brand Name: X-media
Certification: CE/ROHS/ISO/CB/SASO/TUV/FCC/UL
Model Number: P2
Payment & Shipping Terms:
Minimum Order Quantity: 5sq.m
Price: Negotiation
Packaging Details: Flight case, wooden case and carton box and foam package
Delivery Time: 8~10 working days
Payment Terms: T/T, MoneyGram,Cash
Supply Ability: 5,000sq.m/month

P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels

Description
Product Name: Indoor Advertising Led Display Panels Cabinet Material: Iron/Die-casting Aluminum
Module Size: 256mmx128mm Screen Dimension: Customized Design
Brightness: >1500cd Warranty: 5 Years
Life Span: 100000H MTBF: 10000H
High Light:

P2 Indoor Full Color LED Display

,

128x64 LED Video Wall Panels

,

128x64 Indoor Full Color LED Display

P2 Indoor Meanwell Power Supply Led Display Panels Light Weight



♦ Small Pixel LED Screen for Clearer Pictures

The Small Pixel LED Display features small pixel modules which presents clearer and vivid images even in low brightness and dark days. The display is suitable for various applications including security monitoring center, scheduling command platform, smart city, television studio and high-end meetings.



Methods for Quality Assurance
a. Aging
1) 100% fully test
2) Condition: 72 hours with 256 grey level
b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range

♦ Applications

LED display can be widely used in advertising,multi-media,stadium,stage,rental show,transit directions,etc.





♦ Product specification

indoor SMD P2
Lamp size 1515
Resolution/mm 2mm
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 250000/m²
Module resolution 128x64
Module size/mm 256*128
View distance ≥0.5m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode 1/32
Frame rate 60Hz
Refresh frequency >1600Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <1100W
Average power:/㎡ <280W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%










P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels 0



P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels 1



♦ Production process:

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing



♦ Our advantages

Professional Manufacturer of led display

1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 8-10 working days

8. Excellent R&D team,factory Price and assure you quality goods.



♦ Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

♦ Why choose us:

Continues Quality

With more than 12 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.





Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.

P2 Indoor Full Color LED Display , 128x64 LED Video Wall Panels 2
