Product Details:
|
| Product Name: | Advertising Led Screen | Cabinet Material: | Aluminum |
|---|---|---|---|
| Module Size: | 320mmx160mm | Screen Size: | Customized Design |
| Brightness: | 6000cd | Warranty: | 5 Years |
| Life Time: | 100,000H | MTBF: | 10,000H |
| High Light: | P4mm Commercial Led Display Screen,KingLight Advertising Display Board,KingLight Commercial Led Display Screen |
||
P4 Tricolor Holiday Advertisement LED Display, Commercial Led Screen
Shenzhen X-Media Technology Co.,Ltd has the standard new factory, and about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display, led wireless car used screen, transparent screen, poster screen etc. It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality, good price product market to price product market to provide perfect product and service for our customers in world
About our led displays
Competitive Price
With large scale production capacity and professional production technology,our company have built effective modular production.We always stick to promote the technical innovation and reduce cost to benefit customers.
Fast Delivery
Once we promise the delivery date, we will try our best to fulfill it.Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.
After-sales:We will track the products usage and then constantly perfect our products.
Application
Entertainment venues ,broadcast, auditoriums, stage events, malls, market squares, offices, hotels, restaurants, banquets ,
sports, entertainment and other special event.
Outdoor stage shows ,big concert, wedding background , media Facade , Video Productions
perfect display solution for outdoor events such as exhibitions, conferences, awards shows, experimental marketing and corporate events
Module Parameter
| Pixel pitch | 4mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD 3535 |
| Module size | 256x128mm |
| LED lamp | KingLight or Nationstar |
| Module resolution | 64x32dots |
| Module quantity per cabinet | 8pcs |
Cabinet Parameter
| Cabinet size | 512x512mm |
| Cabinet material | die casting aluminum |
| Cabinet weight | 9kg |
| Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter
| Pixel density | 62500 dots/m² |
| Brightness | ≥6000 cd/m² |
| Viewing angle | H≥120° V≥120° |
| Min.viewing distance | 4m |
| Max.power consumption | 1000W/m² |
| Avg.power consumption | 480 W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 14-16bits |
| Frame frequency | ≥60frames/s |
| Refresh rate | ≥3840Hz |
| MTBF | ≥10000 hours |
| Lifespan | ≥50000 hours |
| Protective function | Over-heat/Over-load /Power-down /Power-leakage /Lightning-protection etc. |
| Operating temperature | -10℃ ~ +40℃ |
| Operating humidity | 10-80% no condensation |
| Storage temperature | -20℃ ~ +60℃ |
| Storage humidity | 10-85% no condensation |
Control System Parameter
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way | Computer, video-synchronous, real-time, off-line, wireless, internet etc. |
Methods for Quality Assurance
a. Aging
100% fully test Condition: 72 hours with 256 gray level
b. Vibration Testing
Condition: 3-5 min up and down in 5mm range
The epistar Led chip. with SMD and DIP Technology
We adopt the epistar led chip from Taiwan and SMD led display module will be available
The package and shippment
We can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.
we can choose the best shippment which is convenient to you!
X-Media group can give you the short delivery time and With the large production ability ,
you can feel free about this . By air ,by train, by sea?
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.
Competitive Advantage:
1. 5 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6. Small order accepted.
FAQ 1
Q1. Can I have a sample order for led display?
A: Yes, we welcome sample order to test and check quality.We will give for free after you place an order.
Q2. What about the lead time?
A:Sample needs 5-7 days, mass production time needs 8-10 days for order quantity more than
Q3. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q4. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the goods and places deposit for formal order.
Fourthly We arrange the production.
Q5. Is it OK to print my logo on leddisplay product?
A: Yes. Please inform us formally before our production and confirm the design with you.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 5 years warranty to our products.
