Product Details:
|
Product Name: | Indoor LED Display | Cabinet Material: | Iron/Die-casting Aluminum |
---|---|---|---|
Screen Dimension: | 320mmx160mm | Warranty: | 5 Years |
Life Span: | 100,000H | Brightness: | >1500cd |
Highlight: | High Refresh Rate Indoor LED Display,Lightweight Indoor LED Display,Compact Indoor LED Display |
Led Curtain Display Interactive Digital Signage Indoor Led Video Wall P3 Led Display Panels
♦ Product specification
Indoor SMD P5 Full Color LED Display | |||||
Resolution/mm | 5mm | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 40000/square meter | ||||
Module resolution | 64x32 | ||||
Module size/mm | 320x160mm | ||||
View distance | 14-300m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >1500cd/square meter | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/8 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
♦ Description
Durability is a crucial aspect of indoor full-color LED displays, especially in high-traffic environments or permanent installations. Some versions are built with robust materials and advanced engineering to ensure a long lifespan and resistance to wear and tear. These displays are designed to withstand the rigors of constant use, with features like reinforced panels, shock-resistant components, and protective coatings. Versions with enhanced durability are ideal for public spaces, retail environments, and corporate installations where reliability is paramount.
♦ Applications
♦ Our advantages
♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
♦ Why choose us:
Continues Quality
With more than 12 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
