Product Details:
|
| Product Name: | Indoor Fine Pixel Advertising LED Display | Cabinet Material: | Die-casting Aluminum |
|---|---|---|---|
| Module Size: | 200mmX150mm | Screen Dimension: | Customized Design |
| Brightness: | >1000cd | Warranty: | 5 Years |
| Life Span: | 100000H | MTBF: | 10000H |
| High Light: | P1.667 High Resolution LED Display,Anti UV LED Wall Screen Display Indoor,P1.667 LED Wall Screen Display Indoor |
||
GOB LED Wall Screen P1.667 High Resolution with Die-casting Aluminum
♦ The Features of GOB LED Display
1) waterproof
2) dustproof
3) moisture proof
4) anti-collision
5) anti-UV
6)avoid LEDs fall off
GOB 4:3 Design and Good Uniformity
Ultra wide angle of view
Ultra wide angle of view,from any perspective images are clear natural,to experience the great subversive viewing experience
Specifications :
| indoor SMDP1.667 | |||||
| Resolution/mm | 1.667mm | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 359856/m² | ||||
| Module resolution | 120x90 | ||||
| Module size/mm | 200x150MM | ||||
| View distance | 2-80m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1000cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/43 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Function and Technology Character:
1. Support multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on
2. The screen can get singal of camera, video, VCD, DVD, LD, TV and so on.
3. Brightness, contrast, saturation can be adjusted automatically by itself and manual.
4. Clear picture without flicker and distortion.
5. Show everything with your PC synchronously.
6. Super correcting technology for distortion.
7. One interface for sound signal and two ports for video signal at least.
8. Connected and controlled by PC via Lan and remote control.
9. Multiform language are available,such as English, French, Germany, Spanish, Russian and so o
♦ Our advantages
Professional Manufacturer of led display
1. OEM service,No MOQ
2. Easy installation,regular items in Stocks
3. Offering free design drawing as requested.
4. Remote controlling and adjusting are available.
5. Wooden case or flight case,you are the boss.
6. Your reply will be replied within 24 hours.
7. Fast delivery: Usually 8-10working days
8. Excellent R&D team,factory Price and assure you quality goods.
Trade Terms:
1. Payment: T/T, 40% deposits before production, 60% balance to be paid before shippment.
2. Freight charges are quoted under your requests
3. Shipping port: Xiamen, China
4. Warranty time: 5 years.If there is no manmade problems,we will repair for you freely
